If you are comparing a bitumen distributor for sale, one question comes up in almost every inquiry: can the machine be built around your project instead of a fixed catalog spec? Highway priming, fog seals and bonding layers each need different tank volumes, spray widths and control precision, so a standard truck rarely fits every job.
The STBD series from SINOTO (HENAN SINOTO MACHINERY TECHNOLOGY CO., LTD.) is built with configurability in mind. As an experienced bitumen distributor manufacturer, STOM lets buyers choose the chassis, tank size, nozzle layout and operating mode to match their working conditions. This article covers each option so you can specify the right machine with confidence.
💡 Quick Answer: Yes. Chassis brand and drive type, tank capacity, spray width through nozzle combinations, and operating mode can all be tailored. Deeper changes to PLC logic should be confirmed with the engineering team during quotation.
📊 At a Glance: What You Can Configure
| 🚛 Chassis | 🛢️ Tank Capacity | 📏 Spraying Width | 🎛️ Control System |
|---|---|---|---|
| SinoTruck, Shacman, Dongfeng, FAW | 4,000–20,000 L range listed | 1.2–4.5 m standard | IDEC PLC, ±1.5% volume error |
| 4×2, 6×4, 8×4 drive types | 6,000–15,000 L standard models | Adjustable nozzle groups | Manual or automatic mode |
When shortlisting an asphalt distributor for sale, start with the chassis, because it decides payload, fuel economy, road legality and after-sales support in your market.
STOM builds its distributors on SinoTruck, Shacman, Dongfeng or FAW chassis, so you can pick the brand your local workshops and spare-parts dealers already support. Drive configurations depend on the model:
Power is another choice: an independent auxiliary engine or a PTO (power take-off). The auxiliary engine lets the system spray from zero speed, which matters at start-up points and in slow, precise work.
Tank capacity should follow project scale. The product page lists tanks from 4,000 to 20,000 L, and the standard models are compared below.
| Model | Tank (L) | Chassis | Nozzles | Spray Width (m) | Bitumen Pump | Total Weight (kg) |
|---|---|---|---|---|---|---|
| STBD-6000 | 6,000 | 4×2 | 28 | 1.2–4.0 | QGB680 | 14,000 |
| STBD-8000 | 8,000 | 4×2 | 28 | 1.2–4.5 | QGB680 | 19,000 |
| STBD-10000 | 10,000 | 4×2 / 6×4 | 32 | 1.2–4.5 | QGB950 | 20,000 |
| STBD-12000 | 12,000 | 6×4 | 32 | 1.2–4.5 | QGB950 | 31,000 |
| STBD-15000 | 15,000 | 6×4 | 32 | 1.2–4.5 | QGB950 | 33,000 |
A practical rule: smaller tanks reduce refill frequency on short urban jobs, while 12,000–15,000 L units cut downtime on long highway sections. A reliable asphalt distributor manufacturer should ask about your typical daily spray area, refilling distance and road-weight limits before recommending a tank.
Spraying width is where a bitumen sprayer for sale proves its flexibility. Instead of fixed coverage, the STBD series uses an industrial computer that supports customizable nozzle combinations, so operators can switch nozzle groups on or off to match the lane or patch being treated.
Key features that support width customization:
🔧 Which width fits which job?
| Application | Typical Need | Configuration Tip |
|---|---|---|
| Prime coat / tack coat | Full lane coverage | Use the maximum width, up to 4.5 m |
| Fog seal | Uniform light application | Low application rate, full nozzle set |
| Patching and urban roads | Narrow or irregular areas | Fold the bar and reduce active nozzles |
| Waterproof layers | Precise volume control | Automatic mode with parameter feedback |
Buyers who need coverage beyond the standard range should raise it early, since the product page also mentions widths up to 6,000 mm. Anyone evaluating an asphalt sprayer for sale should ask for the exact nozzle count and bar design confirmed in writing.
Even a well-specified tank and bar deliver poor results without accurate control. Every STBD model runs an IDEC PLC with an industrial computer, and the system works as follows:
This means each square meter receives the specified amount of binder, even when speed changes. Operators can also switch to manual mode for individual nozzles when a job demands it.
Supporting components reflect the same reliability focus: a DanFoss hydraulic pump, HydraForce proportional valves, and a RIELLO imported burner with auto-ignition and temperature control. Thermal oil circulation heats the nozzles, pipes and pumps to prevent clogging, and it lets the truck keep asphalt hot on long transfers without external heating.
⚠️ Buyer’s Note: Operating modes, nozzle logic and spray parameters are adjustable in normal use. If you need custom PLC programming, interface language changes or special sensors, ask your bitumen sprayer manufacturer to confirm feasibility and lead time in the quotation stage.
Buyers naturally ask about bitumen distributor price first, but STOM does not publish a fixed figure because each truck is configured to order. The same is true of any asphalt distributor price you will see quoted online: the number depends on the specification behind it.
Here are the main factors that move a bitumen distributor truck price:
| Cost Factor | Effect on Quote |
|---|---|
| Chassis brand and drive (4×2 / 6×4 / 8×4) | Often the largest single component |
| Tank capacity (6,000–15,000 L+) | Larger tank means more steel, insulation and heating |
| Nozzle count and spray bar design | Wider bars and more nozzles add cost |
| Power take-off type (auxiliary engine vs. PTO) | Independent engine adds hardware |
| Control and options (lighting, tire sprayers, cab A/C) | Custom features raise the total |
| Destination, emission standard and shipping | Affects logistics and compliance |
When comparing offers, look beyond the headline bitumen sprayer price. A low asphalt sprayer price may leave out the auxiliary engine, the thermal oil circulation or the branded pumps, and those items affect long-term uptime. Likewise, ask suppliers for a complete itemized bitumen sprayer truck price and asphalt distributor truck price, and for the same for an asphalt sprayer truck price, so quotes can be compared line by line. Delivery time, warranty terms and spare-parts availability deserve the same attention as the sticker figure.
Customization is a normal part of buying a bitumen distributor: chassis, tank size, spray width and operating mode can all be matched to your roads, your climate and your fleet. The most efficient way to start is to share four details with your supplier:
With those in hand, STOM’s engineers can propose the right STBD model. Whether you are looking for an asphalt distributor for sale for highway work or a compact unit for municipal maintenance, a tailored configuration protects both your budget and your spray quality.
